HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-5
2.1.2 Decathlon HD60 Primary Components (includes SCFHD units) (cont.)
ITEM PART # COMPONENT
14 211-4570 Side Panel, Left Side (unit exterior)
15 212-4570 Side Panel, Right Side (unit exterior)
* 201-4775 Side Panel, Left Side with Hole (unit interior)
* 202-4775 Side Panel, Right Side with Hole (unit interior)
* 211-5693 Side Panel, Left Side, Single (unit exterior)
* 212-5693 Side Panel, Right Side, Single (unit exterior)
* 231-2311 Side Panel, Left Side (unit exterior, SCFHD60 C/C)
* 232-2311 Side Panel, Right Side (unit exterior, SCFHD60 C/C)
* 231-2311 Side Panel, Left Side (unit exterior, HD63)
* 232-2311 Side Panel, Right Side (unit exterior, HD63)
* 201-1245 Panel, Inner Left (divider located over filter unit)
* 202-1245 Panel, Inner Right (divider located over filter unit)
* 201-4237 Panel, Inner Left (divider located over filter unit), Church's
* 202-4237 Panel, Inner Right (divider located over filter unit), Church's
16 200-1327 Back Panel, Lower (Single)
* 200-1222 Back Panel, Lower (Double)
* 200-4238 Back Panel, Lower (Church's Double)
* 200-1213 Back Panel, Upper (Single)
17 824-1195 Wireway, Control Panel
18
►►► See Control Panel Options, Joiner Strips, and Accessories, Section 2.3
19
Top Cap
* 824-0987 x1 (Single)
* 824-0937 x2 (2-battery)
* 824-0992 x3 (3-battery)
* 824-0960 x4 (4-battery)
* 106-6080 x3 (3-battery, SCFHD60 C/C)
* 106-4683 x4 (4-battery, SCFHD60 C/C)
* 106-5434 x1 (Single, HD63)
* 106-6080 x3 (3- and 6-battery, HD63)
* 106-4683 x4 (4- and 6-battery, HD63)
20 106-4375 Flue Box Assembly (also used on HD63 fryers)
* 200-8220 Front, Flue Box
* 200-8221 Back, Flue Box
* 200-8219 Shield, Flue Box
* 200-3649 Deflector, Flue (Single, HD, non-S/S) (use screws 809-0437)
* 210-6525 Deflector, Flue (Single, Chili's, S/S) (use screws 809-0437)
21 823-3635 Flue Cap (Single)
* 823-3516 Flue Cap (2-battery)
* 230-1850 Flue Cap (HD63)
22 106-4721 Door Assembly, Left
* 200-4794 Panel, Door, Inner
* 211-8935 Panel, Door, Outer
* 106-4722 Door Assembly, Right
* 200-4794 Panel, Door, Inner
* 212-8935 Panel, Door, Outer
23 106-4309 Door Assembly (SCFHD60 C/C)
* 200-8076 Panel, Door, Inner
* 210-8075 Panel, Door, Outer
* Not illustrated.
