HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-6
2.1.2 Decathlon HD60 Primary Components (includes SCFHD units) (cont.)
ITEM PART # COMPONENT
24 810-0180 Handle, Door, Wireform
25 210-8077 Handle, Door, Common Cabinet
* 810-1105 Magnet, Door
* 803-0304 Fry Basket, Twin
26 803-0149 Grid Assembly, Mesh
* 810-2235 Grid Assembly, Rack
27 210-2737SP Basket Hanger, Single, no Splash Guard
* 823-4999 Basket Hanger, Chili’s Double System, 6” Splash Guard
28 810-0356 Caster, Plate-mount 5" without Brake
* 810-2406 Caster, Single Stud-mount 5" without Brake
29 810-0357 Caster, Plate-mount 5" with Brake
* 810-2405 Caster, Single Stud Mount 5" with Brake
30 812-1226SP Drain Nipple, Extended, 1 ¼”
*
812-1717SP Drain Nipple, Extended, 1 ½”
* 106-0913SP Cordset, 10’ Power
31 210-9416 Cover, Outlet Duct
32 810-2411 Leg, Single Bolt Mount (black)
* 810-3169 Leg Package, 4 Bolt Mount (4 per set)
33 823-3248 Leg Support Assembly
34 200-8835 Burner Mounting Rail
* 200-2308 Post, Door
* 201-1182 Gusset, Side Panel Left
* 202-1182 Gusset, Side Panel Right
* 200-1611 Base, Cabinet
* 210-9416 Duct, Door Access
* 200-2713 Plate, Suction Manifold
* 210-1180 Insert, Suction Manifold
35 220-0891 Brace, Front Horizontal, Single (SCFD C/C)
* 220-0882 Brace, Front Horizontal, Double (SCFD C/C)
* Not illustrated.
2.1.3 Decathlon FPHD65 Primary Components
ITEM PART # COMPONENT
1 823-5243 Frypot - S/S
2 810-2072 Gas Manifold (weld assembly)
3
►►►
See Orifices, Section 2.2
4 810-2032 Pilot Burner, Natural/G20/25 Gas (primary and trailing, 120V)
* 810-2155 Pilot Burner, LP/G31 Gas (primary and trailing)
* 812-1674 Pilot Burner, Mod. Natural Gas (electronic ignition)
* 810-0705
Tube, Pilot Gas Supply,
1
⁄
4
" x 23" (one-piece gasline)
* 810-0703
Tube, Pilot Gas Supply,
1
⁄
4
" x 17
1
⁄
2
" (one-piece gasline)
5 220-1231 Bracket, Manifold Support (right or left)
6 230-1431 Diffuser Assembly
7
►►► See Drain Manifold Components, Section 2.5
8 810-2785 Burner, High Efficiency
9 200-8748 Heat Shield, Lower
* 200-8053 Heat Shield, Vessel
* 230-2057 Support, Burner
