Frymaster Dean FPHD - Page 55

HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-7
2.1.3 Decathlon FPHD65 Primary Components (cont.)
ITEM PART # COMPONENT
10 807-3552 Gas Valve, Natural Gas, Electronic Ignition, 24 VAC
* 807-3628 Gas Valve, LP Gas, Electronic Ignition, 24 VAC
* 807-3294 Gas Valve, Natural Gas, Constant Pilot, 24 VAC
* 807-3295 Gas Valve, LP Gas, Constant Pilot, 24 VAC
* 810-2156 Gas Valve, Natural Gas, 120 VAC
* 810-2323 Gas Valve, LP Gas, 120 VAC
* 807-2091 Gas Valve, G20/G25 Gas, 24 VAC (CE only)
* 807-2127 Gas Valve, G31 Gas, 24 VAC (CE only)
* 810-0691 Vent Tube
* 823-3347 Frame, Slide Base
11
Channel, Base
* 106-7441 265
* 106-7357 465
* 106-6851 565, 665
12 823-4894 Hinge, Lower Left
* 823-4895 Hinge, Lower Right
13 823-5136 Hinge, Upper Left
* 823-5137 Hinge, Upper Right
14 211-8078 Side Panel, Left Side (unit exterior)
15 212-8078 Side Panel, Right Side (unit exterior)
* 221-0012 Side Panel, Left Side with Hole (unit exterior)
* 222-0012 Side Panel, Right Side with Hole (unit exterior)
* 201-4237 Panel, Inner Left (divider located over filter unit)
* 202-4237 Panel, Inner Right (divider located over filter unit)
16
Cabinet Upper Back
* 220-2474 x1 (Single)
* 220-2353 x2 (2-, 4-, 5-, and 6-battery)
* 220-0668 x3 (5-battery)
*
Cabinet Lower Back
* 220-2483 x1 (Single)
* 220-2354 x2 (2-, 4-, 5-, and 6-battery)
* 220-0667 x3 (5-battery)
17 824-1195 Wireway, Control Panel
18
►►► See Control Panel Options, Joiner Strips, and Accessories, Section 2.3
19
Top Cap
* 824-1781 x1 (for single)
* 823-6010 x2 (for 2-battery)
* 823-6011 x4 (for 4-battery)
* 823-6090 x3 (for 5-battery)
* 823-5975 x2 (for 5- and 6-battery)
* 823-5976 x4 (for 6-battery)
* 824-1656 x3, with work shelf
* 230-2472 x1, HD Marine
20 106-4375 Flue Box Assembly
* 200-8220 Front, Flue Box
* 200-8221 Back, Flue Box
* 200-8219 Shield, Flue Box
* 200-3649 Deflector, Flue (Single, HD, non-S/S) (use screws 809-0437)
* 210-6525 Deflector, Flue (Single, Chili's, S/S) (use screws 809-0437)
* Not illustrated.
