6.2.2 Fryer Heating Oil (cont.)
Elements continue to heat and
maintain proper temperature
(will cycle during melt)?
Unit stops heating with heat light on:
- Defective or improperly installed
high limit
- Defective heating or latching
contactor
Unit heats until high limit trips without
heat light on:
- Defective heating element
- Defective heating contactor
- Improperly wired element
Unit heats until high limit trips with heat
light on:
- Defective (shorted) probe
- Defective computer/controller/timer
NO
Condition Normal
YES
Continued from previous page
