Frymaster H14 Series - Troubleshooting Built-in Filtration System

6-6
Troubleshooting The Built-in Filtration System
Allow motor to cool for at
least 45 minutes then press
Thermal Overload Switch
reset button and move filter
handle to ON position.
Did pump start and
continue to run?
Problem
resolved.
Move filter handle to OFF position.
Allow oil/shortening to cool, then
empty pan and verify that filter paper
and screen have been properly
installed and are clean. Refill pan and
move filter handle to ON posistion.
Did pump
start and then abrubtly
stop?
Reset Thermal
Overload switch.
Remove filter pan
and move handle to
ON position.
Does pump
run okay?
Did motor hum
for a short time and then
stop?
Is filter
wiring harness properly
connected at both ends and free
of cuts, breaks, or other
signs of damage?
Press Thermal Overload
Switch reset button and
move filter handle to ON
position.
Did pump
start and continue
to run?
Problem
resolved.
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
NoYes
No
No Yes
Did pump start and
continue to run?
Is pump motor hot (cannot
hold hand on pump)?
PUMP WON'T
START.
Verify that filter
power cord is
plugged in and that
circuit breaker is on.
Probable cause is failed
filter handle microswitch.
Call FASC or Frymaster
Service Department
What happened?
Yes
No
PUMP
STOPPED DURING
FILTERING PROCESS AND
WON'T RESTART.
PUMP WON'T
START AFTER BEING
OFF FOR AT LEAST
ONE HOUR.
Does pump start
if a different filter handle is
activated?
Probable cause is a
pump blockage. Pump blockages are
usually caused by sediment buildup
in the pump due to improperly sized
or installed filter paper. Call FASC or
Frymaster Service Department.
If filter harness is properly
connected but is damaged,
probable cause is failed wiring
harness. Order replacement from
FASC or call Frymaster
Service Department.
Probable causes are a
failed 24-volt transformer or
a defective motor. Call FASC
or Frymaster Service Department.
Probable cause is a
blockage of the filter pan suction
tube. Remove blockage using a thin,
flexible wire and attempt to operate
filter. If unable to remove blockage,
call FASC or Frymaster Service
Department.
