Rack Mounting
Site Environment
Installing
Do not operate it in an area that exceeds an ambient temperature of 40°C or nearby heat sources.
The installation site should be well ventilated.
Be sure that the KVM switch is level and stable to avoid any hazardous conditions.
Do not install the equipment in a dusty environment.
The installation site must be free from leaking or dripping water, heavy dew, and humidity.
Ports Description
A power input port for AC power cord.
Turn on/o the power.
A power input port for DC power cord.
Connect the remote computer for remote control.
Connect external keyboard, mouse and monitor for local
control.
Connect computer or server.
For grounding the KVM Switch.
Reserved port for hardware upgrading.
Power Input (AC)
Power Switch
Power Input (DC)
LAN Port
USB Port
HDMI Port
RJ45 Ports
Ground Connecting Screw
RS485 Port
