FuelTech Nano PRO - Lambda Readings Analog Outputs; Lambda Analog Output in Volts - 5.14 to 17.6 AFR; Lambda Analog Output in Volts - 8.7 to 16.2 AFR (Default); Lambda Analog Output in Volts - 9.6 to 19.1 AFR

NANO PRO
19
AFR (Gasoline)
AFR
(Methanol)
Lambda
4.120 1.800 0,280
6.470 2.820 0,440
7.640 3.340 0,520
8.530 3.720 0,580
9.260 4.040 0,630
10.000 4.370 0,680
10.580 4.620 0,720
11.170 4.880 0,760
11.760 5.140 0,800
12.500 5.460 0,850
13.380 5.840 0,910
14.700 6.420 1,000
16.320 7.130 1,110
18.380 8.030 1,250
21.020 9.180 1,430
11. Analog output Lambda/AFR
AFR (Gasoline)
AFR
(Methanol)
Lambda
24.400 10.660 1,660
26.460 11.560 1,800
28.960 12.650 1,970
32.050 14.000 2,180
35.720 15.600 2,430
40.430 17.660 2,750
46.310 20.220 3,150
53.950 23.560 3,670
59.240 25.870 4,030
65.420 28.570 4,450
72.770 31.780 4,950
82.320 35.950 5,600
110.250 48.150 7,500
167.870 73.320 11,420
343.250 149.910 23,350
470.400 205.440 32,000
Lambda AFR Gasoline AFR Methanol/Ethanol
Volts
(V)
0,35 5,14 2,3 0,20
1,20 17,6 7,7 4,80
10.3 Lambda Analog Output in Volts – 9.6 to
19.1 AFR
Lambda AFR Gasoline AFR Methanol/Ethanol
Volts
(V)
0,65 9,6 4,2 0,20
1,30 19,1 8,3 4,80
10.4 Lambda Analog Output in Volts – 9.6 to
58.8 AFR
Lambda AFR Gasoline AFR Methanol/Ethanol
Volts
(V)
0,65 9,6 4,2 0,20
4,00 58,8 25,7 4,80
10.5 Lambda Analog Output in Volts – 9.6 to
146.9 AFR
Lambda AFR Gasoline AFR Methanol/Ethanol
Volts
(V)
0,65 9,6 4,2 0,20
9,99 149,9 64,1 4,80
When there is an output reading error, the analog output locks
at 0.00V. Thus, it is possible to know if there is any problem
or error in the equipment. To congure this output on external
equipment, it is necessary to supply the rst and last values of
the table above.
10.2 Lambda Analog Output in Volts – 8.7 to
16.2 AFR (default)
Lambda AFR Gasoline AFR Methanol/Ethanol
Volts
(V)
0,59 8,7 3,8 0,20
1,10 16,2 7,1 4,80
10. Lambda Readings analog outputs
10.1 Lambda Analog Output in Volts – 5.14 to
17.6AFR
