Copy
168
Copy
3
îš‹ Sideways Images
Select this option when placing the top edge of the document against the left side of the
document glass or document feeder. Always select [Sideways Images] when the top of the
document is placed facing the left side (horizontal text).
îš„ Z Fold Half Sheet
The machine folds the output copies in Z fold. Z fold can be applied to B4, A3, 11 x 17". If
you have mixed sized documents, the width (vertical direction) of the paper must be the
same, such as a combination of A4 (portrait) and A3 (landscape), and a combination of B5
(portrait) and B4 (landscape). When you have the combinations, the Z fold is only applied
to the larger papers (A3(landscape) and B4 (landscape)).
îš„ Output/Offset
Allows you to select the output destination tray and offset operation.
îš„ Offset Stacking
Available when the output destination tray is not selectable.
z
This feature does not appear for some models. An optional component is required. For more information,
contact our Customer Support Center.
Paper Size and Stapling Position
îš„ Finisher A2
* : The staple orientation displayed on the touch screen differs from the actual staple orientation. Outputs are stapled in the
orientation shown in the above table.
1 Staple 1 Top
Right
2 Staples 2 Top 2 Right
A4 , A4 Cover , B5 ,
7.25 x 10.5" ,
8 x 10" , 8.5 x 11" ,
9 x 11" , 16K
A4, A3, B4,
8.46 x 12.4",
8.5 x 11",
8.5 x 13",
8.5 x 14",
11 x 15",
11 x 17", 8K
To Next Page
