15 Appendix
562
Appendix
15
Pen attributes 800-815
(Pen width)
(No. 0-No.15)
Set the width (thickness of the line) of the 16 pens (No. 00 to 15). You can set
the width from 0.0 to 25.5 mm in 0.1 mm increments. No. 00 denotes Item
No. 800.
[0] - [255] (Default: 3) : 0 to 25.5 mm
Note • If the image is reduced by concern with the relationship between
[Document size] and [Paper size] settings, the pen width is reduced
accordingly to 0.1 mm at the smallest.
• The width of the line gets thick symmetrically with respect to the center of
the line.
• If the width is set to 0.0 mm, nothing is plotted.
850-865
(Line end
shape)
(No. 0-No.15)
Set the line end shape of the 16 pens (No. 00 to 15). No. 00 denotes Item No.
850.
[0] (Default) : Cut
[1] : Round
[2] : Rectangular
[Cut]
: specified coordinate
[Round]
: specified coordinate
[Rectangular]
: specified coordinate
Parameter Item No. Value
To Next Page
