Fuji Xerox DocuPrint CM415 AP

Cleaning the Machine
67
Maintenance
3
8 Turn the control panel to the left.
9 Open the top cover.
10 Put your fingers through the loops on both
sides of the belt unit, and then pull it out.
11 Clean the CTD sensor with a clean dry cotton
swab.
12 Close the rear cover.
13 Reinsert the belt unit into the machine.
