Features
2 - English A26361-D1215-Z181-1-7619
Features
The table shows two assembly versions of this system board as example.
Features
D1214-A D1215-A
Chipset Intel 815E
Board Size m-ATX m-ATX
VGA onboard (Intel 815E) üü
Audio onboard (AC '97) üü
LAN onboard / with Alert-on-LAN ü / - ü / ü
Thermal Management onboard - ü
System Monitoring onboard - ü
Fujitsu Siemens Keyboard Power Button Support - ü
Buzzer onboard / int. Speaker Support ü / - - / ü
Internal Connectors
DIMM Sockets (SDRAM) 2 2
AGP Slot (1/2/4x, 32Bit, 66 MHz) 1 1
PCI Slots (32Bit, 33 MHz, 5 V and 3.3 V) 3 3
ISA Slot - -
ACR Slot - -
AMR Slot - -
IDE Interfaces (Ultra DMA/100) 2 2
Floppy Interface (up to 2.88 MB) 1 1
CD / AUX Audio Input 1 / 1 1 / 1
Wake-on-LAN 1 1
Int. Serial Port / with SmartCard Support 1 / ü 1 / ü
USB Connectors int. / shared with CNR 2 / - 2 / -
External Connectors D1214-A D1215-A
VGA 1 1
Audio Mic. / in / out (2 x 0.5 W / 8 W)11
Game/MIDI 1 1
LAN (RJ-45) 1 1
PS/2 Mouse/Keyboard 1 1
Ext. Serial Port (FIFO, 16550 compatible) 1 1
Parallel Port (EPP/ECP) 1 1
USB Connectors external 2 2
