Mechanics
10 - English A26361-D1215-Z181-1-7619
Configuration
Functions controlled by the configuration switch
Function SKP RCV FWP PSS
Password skip on X X X
Off off X X X
Recovery BIOS X on X X
Off X off X X
Floppy write protect X X on X
Off X X off X
Low auxiliary power supply (<2 A) X X X on
High auxiliary power supply X X X off
PSS must be switched on for systems with not enough 5 V auxiliary power for all its self powered
wake devices (WakeOnLAN, USB, PCI) in S3-S4.
Power
Power requirement
Source Voltage Maximum variation Maximum current Comment
Main power supply +5.0 V ±5 % 15 A
Main power supply +12 V ±5 % 350 mA
Main power supply -12 V ±10 % 200 mA
Main power supply +3.3 V ±5 % 4 A
Auxiliary power supply +5.0 V ±5 % 2 A
Power loadability
Fuse
number
Maximum fuse
current
Function Maximum function current
1 750 mA Keyboard port Not specified
Mouse port Not specified
Game port Not specified
2 500 mA Universal serial bus (USB) Port A 500 mA
3 500 mA Universal serial bus (USB) Port B 500 mA
