Fujitsu Siemens Computers D1215 - Mechanics

Mechanics
A26361-D1215-Z181-1-7619 English - 3
Mechanics
Layout
mATX 9.6" x 8’’ (243.84 mm x 203.2 mm)
Some of the following connectors are optional and may therefore not be included on your system
board.
1
2
3
4
5
6
7
8
9a9b9c
1 = PS/2 mouse port
2 = PS/2 keyboard port
3 = LAN port
4 = USB ports A and B
5 = Parallel port
6 = Serial port 1
7 = VGA port
8 = Game/Midi port
9a = Audio Line-Out
Headphones
9b = Audio Line-In
9c = Audio Micro-In
The components and connectors marked are not necessarily present on the system board.
