Board Installation
A26361-D1818-Z120-1-7619, edition 1 5
Board Installation
!
The mainboard D1818 supports EPS12V/SSI type power supplies (24pin + 8pin) and will
not operate with any other types. For proper power supply installation procedures see
"Installing the power supply” section
DO NOT USE ATX 2.x, ATX12V or ATXGES power supplies as they will damage the
board and void your warranty.
Board Image
This picture is representative of the latest board revision available at the time of publishing. The
board you receive may or may not look exactly like the above picture.
The following page includes details on the vital components of this motherboard.
