Board Parts, Jumpers and Connectors
A26361-D1818-Z120-1-7619, edition 1 13
3. Jumper
2) PWR_JP
3) CLR_CMOS1
4) BIOS_RE
5) BIOS_WP
Jumper Legend
OPEN - Jumper OFF without jumper cover
CLOSED - Jumper ON with jumper cover
î
Key Pin Missing pin to indicate proper orientation
