Board Parts, Jumpers and Connectors
8 A26361-D1818-Z120-1-7619, edition 1
A. CPU0 1. FAN1
B. CPU1 2. FAN4
C. NVIDIA nForce Pro 2200 3. FAN3
D. NVIDIA nForce Pro 2050 4. FAN2
E. AMD8132 5. IO4_FAN
F. Broadcom BCM5751T 6. CK-804_FAN
G. ITE IT871 2F-A 7. SLOT1 PCI –X 133 MHz
H. BIOS 8. SLOT2 PCI-X 133 MHz
I. IDE1 9. SLOT3 PCI-E x 16 on CK8-04
J. IDE2 10. SLOT4 PCI-E x 1
K. FDD 11. SLOT5 PCI-E x 16 on IO4
L. F_1394 12. SLOT6 PCI 33 MHz 5V
M. F_USB2 13. DIMM4~7
N. F_USB1 14. DIMM 0~3
O. SATA0 15. AUDIO
P. SATA1 16. USB_LAN2
Q. SATA2 17. USB_LAN1
R. SATA3 18. REAR_1394
S. F_Panel_FS 19. SPDIF_OUT (not supported)
T. Battery 20. LPT
U. CI 21. COM
V. WOL (Wake On LAN) 22. KB_MS (Keyboard/Mouse)
W. F_AUDIO 23. ATX1 (SSI power connector)
X. WOR (Wake On Ring) 24. ATX2 (SSI power connector)
Y. AUX_IN 25. PC 2004 (power connector)
Z. CD_IN1 26. LCD
