Removing and installing components
during servicing
2
1
► Place the cover on its mounting location (1), en suring it snaps into place.
► Fasten the cover with the screw (2).
► Install the battery again (see "
Insertin g the battery", Page 16).
► Turn the notebook the right way up and place it on a flat surface.
► Reconnect the cables that you d isconnected previously.
24 A26391-K225-Z120-1-7619, edition 1
