4 Handling the Rack after Installation 147
E
5 Remove the door-side hinges and the handle hole cover.
・ Remove the M5 hexagon socket bolts to remove the door-side hinges.
・ To remove the handle hole cover, remove the M4 hexagon nuts with flange.
Door-side hinge
M5 hexagon
socket bolt
Handle hole cover
M4 hexagon nuts with flange
