S e c t i o n T h r e e

P O I N T

All I/O addresses in Table 3-5 are in

hexadecimal.

Menu Field Options Default Description

COM Port: 3F8, IRQ 4; 2F8,IRQ 3; 3F8, IRQ 4 Sets the serial port address and interrupt level.

3E8,IRQ 4; 2E8,IRQ 3;

3F8,IRQ 11; 2F8,IRQ 10;

3E8,IRQ 11;2E8, IRQ 10;

Disabled

IR Port 3F8, IRQ 4; 2F8,IRQ 3; 3E8, Disabled Sets the infrared port address and interrupt level.

IRQ 4; 2E8,IRQ 3; 3F8,IRQ

11; 2F8,IRQ 10;3E8, IRQ 11;

2E8,IRQ 10; Disabled

IR Mode: Standard;Fast,DMA Standard Sets the infrared port mode.

CHANNEL 1; Fast,DMA

CHANNEL 3

Table 3-5 Fields, Options and Defaults for the Integrated Peripherals Submenu

Fujitsu 735Dx User Manual
