5-2. HEATING OPERATION
5-2-1 HEATING CAPACITY CONTROL
A sensor (room temperature thermistor) built in the indoor unit will usually perceive
difference or variation between a set temperature and present room temperature, and
controls the operation frequency of the compressor.
The maximum frequency is limited in the range shown in Figure 2 based on the outdoor temperature.
* If the room temperature is lower 3 °C than a set temperature,
the compressor operation frequency will attain to maximum frequency.
* If the room temperature is higher 2.5 °C than a set temperature, the compressor
will be stopped.
* When the room temperature is between +2.5 °C to -3 °C of the setting temperature,
the compressor frequency is controlled within the range shown in Table2.
( Table 2 : Compressor Frequency Range )
( Fig.2 : Limit of Maximum Frequency based on Outdoor Temperature )
05-02
minimum
frequency
maximum
frequency
AO*A30LBTL
23Hz
120Hz
AO*A36LBTL
AO*A30LBTL
C zone
19°C
C zone
B zone 120Hz 88Hz 76Hz 67Hz
17°C
A zone
14°C
B zone
12°C
A zone
Lo Qu
Fan speed mode
Hi Me
Outdoor air
temperature
When the room
temperature drops
When the room
temperature rises
AO*A36LBTL
