8-4. SAFETY DEVICE
AO A30L AO A36L
Current fuse
(NEAR THE TERMINAL)
Current fuse
(FILTER PRINTED CIRCUIT BOARD)
Current fuse
(MAIN PRINTED CIRCUIT BOARD)
Fan motor protection Thermal protection program
High Pressure Protection Pressure Switch
Thermal protection program
(COMPRESSOR TEMP.)
Thermal protection program
(DISCHARGE TEMP.)
Protection form
25A 250V
10A 250V
Model
3.15A 250V
Compressor protection
Circuit protection
OFF : 120°C
ON : 80°C
OFF : 110°C
ON : After 7 minutes
OFF : 140±20°C
ON : 110±20°C
OFF : 4.2±0.1MPa
ON : 3.2±0.15MPa
Circuit protection Current fuse (PCB)
Fan motor protection
Thermal protection program
140±20°C OFF
110±20°C ON
Protection form
Model
3.15A 250V
AB*30LBT
AB*36LBT
