Fujitsu AO G24LBCB Series User Manual

¢
Cooling capacity (Double twin)

Compact cassette type
Model: AUYG18LVLB × 4
AFR
m
3
/h
2,720
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 13.28 2.78 19.42 13.37 2.82 20.08 14.53 2.84 21.40 14.58 2.87 22.07 15.74 2.88 23.39 15.68 2.92 24.72 16.71 2.94
-10 17.26 13.15 2.79 19.23 13.23 2.83 19.88 14.39 2.84 21.20 14.43 2.87 21.85 15.58 2.89 23.16 15.52 2.92 24.48 16.53 2.94
0 17.10 13.03 2.97 19.05 13.11 3.01 19.69 14.24 3.03 20.99 14.29 3.06 21.64 15.43 3.08 22.95 15.37 3.11 24.24 16.37 3.14
5 17.06 13.00 3.10 19.01 13.07 3.15 19.65 14.21 3.17 20.94 14.25 3.20 21.60 15.40 3.21 22.89 15.33 3.24 24.19 16.33 3.27
10 16.88 12.97 3.48 18.81 13.05 3.54 19.44 14.19 3.56 20.72 14.24 3.59 21.37 15.37 3.61 22.65 15.32 3.64 23.94 16.31 3.69
15 16.40 12.82 3.60 18.25 13.03 3.66 18.89 14.17 3.68 20.12 14.21 3.71 20.74 15.35 3.73 21.99 15.29 3.77 23.23 16.28 3.81
20 16.62 12.94 4.01 18.50 13.16 4.07 19.14 14.31 4.09 20.40 14.35 4.13 21.03 15.50 4.15 22.29 15.44 4.20 23.56 16.44 4.23
25 16.78 12.95 4.75 18.69 13.17 4.83 19.33 14.32 4.85 20.61 14.36 4.90 21.24 15.52 4.92 22.52 15.45 4.97 23.79 16.46 5.02
30 16.45 12.31 5.43 18.33 12.51 5.50 18.96 13.61 5.53 20.19 13.65 5.59 20.82 14.74 5.62 22.07 14.68 5.67 23.32 15.65 5.73
35 15.01 12.03 6.05 16.72 12.30 6.14 17.29 13.37 6.18 18.43 13.41 6.24 19.00 14.49 6.27 20.14 14.43 6.33 21.28 15.37 6.39
40 14.86 11.36 5.73 16.55 11.69 5.81 17.12 12.71 5.85 18.25 12.74 5.90 18.81 13.77 5.93 19.94 13.72 5.99 21.07 14.60 6.05
46 11.84 10.29 5.58 13.19 11.05 5.66 13.63 11.71 5.69 14.52 12.06 5.75 14.98 13.02 5.78 15.89 12.97 5.84 16.78 13.80 5.89

Slim duct type
Model: ARYG18LLTB × 4
AFR
m
3
/h
3,760
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 12.91 2.91 19.42 13.00 2.96 20.08 14.13 2.98 21.40 14.18 3.01 22.07 15.30 3.02 23.39 15.24 3.06 24.72 16.24 3.08
-10 17.26 12.79 2.92 19.23 12.87 2.97 19.88 13.99 2.98 21.20 14.03 3.01 21.85 15.15 3.03 23.16 15.09 3.06 24.48 16.08 3.08
0 17.10 12.67 3.11 19.05 12.75 3.15 19.69 13.85 3.17 20.99 13.90 3.20 21.64 15.00 3.22 22.95 14.94 3.26 24.24 15.92 3.29
5 17.06 12.64 3.24 19.01 12.71 3.30 19.65 13.82 3.32 20.94 13.86 3.35 21.60 14.97 3.37 22.89 14.91 3.40 24.19 15.88 3.43
10 16.88 12.61 3.65 18.81 12.69 3.71 19.44 13.79 3.73 20.72 13.84 3.76 21.37 14.94 3.79 22.65 14.90 3.82 23.94 15.86 3.87
15 16.40 12.47 3.77 18.25 12.67 3.83 18.89 13.77 3.86 20.12 13.81 3.89 20.74 14.93 3.91 21.99 14.87 3.95 23.23 15.83 3.99
20 16.62 12.59 4.20 18.50 12.80 4.27 19.14 13.91 4.28 20.40 13.95 4.33 21.03 15.07 4.35 22.29 15.01 4.40 23.56 15.99 4.43
25 16.78 12.59 4.98 18.69 12.80 5.06 19.33 13.92 5.08 20.61 13.96 5.14 21.24 15.09 5.16 22.52 15.03 5.21 23.79 16.00 5.26
30 16.45 11.97 5.69 18.33 12.17 5.77 18.96 13.23 5.79 20.19 13.27 5.86 20.82 14.33 5.89 22.07 14.28 5.94 23.32 15.22 6.01
35 15.01 11.69 6.34 16.72 11.96 6.43 17.29 13.00 6.47 18.43 13.04 6.54 19.00 14.09 6.57 20.14 14.03 6.63 21.28 14.95 6.70
40 14.86 11.04 6.00 16.55 11.36 6.09 17.12 12.36 6.13 18.25 12.39 6.18 18.81 13.38 6.21 19.94 13.34 6.28 21.07 14.20 6.34
46 11.84 10.01 5.85 13.19 10.75 5.93 13.63 11.39 5.97 14.52 11.73 6.02 14.98 12.66 6.06 15.89 12.61 6.12 16.78 13.42 6.18

Floor/Ceiling type
Model: ABYG18LVTB × 4
AFR
m
3
/h
3,120
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 13.28 2.78 19.42 13.37 2.82 20.08 14.53 2.84 21.40 14.58 2.87 22.07 15.74 2.88 23.39 15.68 2.92 24.72 16.71 2.94
-10 17.26 13.15 2.79 19.23 13.23 2.83 19.88 14.39 2.84 21.20 14.43 2.87 21.85 15.58 2.89 23.16 15.52 2.92 24.48 16.53 2.94
0 17.10 13.03 2.97 19.05 13.11 3.01 19.69 14.24 3.03 20.99 14.29 3.06 21.64 15.43 3.08 22.95 15.37 3.11 24.24 16.37 3.14
5 17.06 13.00 3.10 19.01 13.07 3.15 19.65 14.21 3.17 20.94 14.25 3.20 21.60 15.40 3.21 22.89 15.33 3.24 24.19 16.33 3.27
10 16.88 12.97 3.48 18.81 13.05 3.54 19.44 14.19 3.56 20.72 14.24 3.59 21.37 15.37 3.61 22.65 15.32 3.64 23.94 16.31 3.69
15 16.40 12.82 3.60 18.25 13.03 3.66 18.89 14.17 3.68 20.12 14.21 3.71 20.74 15.35 3.73 21.99 15.29 3.77 23.23 16.28 3.81
20 16.62 12.94 4.01 18.50 13.16 4.07 19.14 14.31 4.09 20.40 14.35 4.13 21.03 15.50 4.15 22.29 15.44 4.20 23.56 16.44 4.23
25 16.78 12.95 4.75 18.69 13.17 4.83 19.33 14.32 4.85 20.61 14.36 4.90 21.24 15.52 4.92 22.52 15.45 4.97 23.79 16.46 5.02
30 16.45 12.31 5.43 18.33 12.51 5.50 18.96 13.61 5.53 20.19 13.65 5.59 20.82 14.74 5.62 22.07 14.68 5.67 23.32 15.65 5.73
35 15.01 12.03 6.05 16.72 12.30 6.14 17.29 13.37 6.18 18.43 13.41 6.24 19.00 14.49 6.27 20.14 14.43 6.33 21.28 15.37 6.39
40 14.86 11.36 5.73 16.55 11.69 5.81 17.12 12.71 5.85 18.25 12.74 5.90 18.81 13.77 5.93 19.94 13.72 5.99 21.07 14.60 6.05
46 11.84 10.29 5.58 13.19 11.05 5.66 13.63 11.71 5.69 14.52 12.06 5.75 14.98 13.02 5.78 15.89 12.97 5.84 16.78 13.80 5.89
- 157 -
