6-2. Model: AOYG90LRLA
TC: Total Capacity, SHC: Sensible Heat Capacity, IP: Input Power
¢
Cooling capacity (Twin)

Cassette type
Model: AUYG45LRLA × 2
AFR
m
3
/h
3,800
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 15.87 3.07 22.49 15.97 3.13 23.25 17.36 3.15 24.78 17.43 3.18 25.55 18.81 3.19 27.08 18.73 3.23 28.62 19.96 3.26
-10 19.98 15.71 3.08 22.27 15.81 3.14 23.02 17.19 3.15 24.55 17.24 3.18 25.30 18.62 3.20 26.82 18.55 3.23 28.34 19.76 3.26
0 19.80 15.57 3.29 22.05 15.66 3.33 22.80 17.02 3.35 24.30 17.08 3.38 25.05 18.44 3.41 26.57 18.37 3.44 28.07 19.56 3.47
5 19.75 15.53 3.43 22.01 15.62 3.48 22.75 16.98 3.50 24.25 17.03 3.54 25.01 18.40 3.56 26.51 18.32 3.59 28.01 19.52 3.62
10 19.55 15.50 3.85 21.78 15.60 3.91 22.51 16.95 3.94 24.00 17.01 3.97 24.74 18.37 4.00 26.23 18.31 4.03 27.71 19.49 4.08
15 18.99 15.32 3.99 21.14 15.58 4.05 21.87 16.93 4.07 23.30 16.98 4.11 24.02 18.34 4.13 25.47 18.27 4.17 26.90 19.45 4.22
20 19.24 15.47 4.44 21.42 15.73 4.51 22.17 17.09 4.52 23.62 17.14 4.57 24.35 18.53 4.60 25.81 18.45 4.64 27.28 19.65 4.68
25 19.42 15.47 5.26 21.64 15.73 5.34 22.39 17.11 5.37 23.86 17.16 5.42 24.60 18.54 5.45 26.07 18.47 5.50 27.55 19.67 5.56
30 19.05 14.71 6.01 21.22 14.95 6.09 21.95 16.26 6.12 23.38 16.31 6.19 24.11 17.62 6.22 25.55 17.54 6.27 27.00 18.70 6.34
35 17.38 14.37 6.70 19.35 14.70 6.79 20.02 15.98 6.84 21.35 16.03 6.91 22.00 17.31 6.93 23.32 17.24 7.01 24.65 18.37 7.08
40 17.21 13.57 6.34 19.17 13.96 6.43 19.82 15.19 6.48 21.13 15.23 6.53 21.78 16.45 6.56 23.09 16.39 6.63 24.39 17.45 6.70
46 13.70 12.30 6.18 15.27 13.21 6.26 15.78 14.00 6.30 16.81 14.41 6.36 17.35 15.56 6.40 18.39 15.49 6.46 19.42 16.49 6.52

Duct type
Model: ARYG45LMLA × 2
AFR
m
3
/h
4,200
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 16.26 3.23 22.49 16.36 3.28 23.25 17.79 3.30 24.78 17.85 3.34 25.55 19.27 3.35 27.08 19.19 3.39 28.62 20.45 3.42
-10 19.98 16.10 3.24 22.27 16.20 3.29 23.02 17.61 3.30 24.55 17.66 3.34 25.30 19.08 3.36 26.82 19.00 3.39 28.34 20.24 3.42
0 19.80 15.95 3.45 22.05 16.05 3.50 22.80 17.44 3.52 24.30 17.50 3.55 25.05 18.89 3.58 26.57 18.81 3.61 28.07 20.04 3.65
5 19.75 15.91 3.60 22.01 16.00 3.66 22.75 17.40 3.68 24.25 17.45 3.72 25.01 18.85 3.74 26.51 18.77 3.77 28.01 20.00 3.81
10 19.55 15.88 4.05 21.78 15.98 4.11 22.51 17.37 4.14 24.00 17.43 4.17 24.74 18.81 4.20 26.23 18.75 4.24 27.71 19.96 4.29
15 18.99 15.69 4.19 21.14 15.96 4.25 21.87 17.34 4.28 23.30 17.39 4.31 24.02 18.79 4.34 25.47 18.72 4.38 26.90 19.93 4.43
20 19.24 15.84 4.66 21.42 16.11 4.74 22.17 17.51 4.75 23.62 17.56 4.80 24.35 18.98 4.83 25.81 18.90 4.88 27.28 20.13 4.92
25 19.42 15.85 5.53 21.64 16.12 5.61 22.39 17.53 5.64 23.86 17.58 5.70 24.60 19.00 5.73 26.07 18.92 5.78 27.55 20.15 5.84
30 19.05 15.06 6.31 21.22 15.32 6.40 21.95 16.66 6.43 23.38 16.71 6.50 24.11 18.05 6.53 25.55 17.97 6.59 27.00 19.16 6.66
35 17.38 14.72 7.03 19.35 15.06 7.14 20.02 16.37 7.18 21.35 16.42 7.26 22.00 17.74 7.29 23.32 17.66 7.36 24.65 18.82 7.43
40 17.21 13.90 6.66 19.17 14.31 6.75 19.82 15.56 6.80 21.13 15.60 6.86 21.78 16.85 6.89 23.09 16.79 6.97 24.39 17.88 7.04
46 13.70 12.60 6.49 15.27 13.53 6.58 15.78 14.34 6.62 16.81 14.76 6.68 17.35 15.94 6.72 18.39 15.87 6.79 19.42 16.89 6.85

Ceiling type
Model: ABYG45LRTA × 2
AFR
m
3
/h
4,200
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 15.87 3.07 22.49 15.97 3.13 23.25 17.36 3.15 24.78 17.43 3.18 25.55 18.81 3.19 27.08 18.73 3.23 28.62 19.96 3.26
-10 19.98 15.71 3.08 22.27 15.81 3.14 23.02 17.19 3.15 24.55 17.24 3.18 25.30 18.62 3.20 26.82 18.55 3.23 28.34 19.76 3.26
0 19.80 15.57 3.29 22.05 15.66 3.33 22.80 17.02 3.35 24.30 17.08 3.38 25.05 18.44 3.41 26.57 18.37 3.44 28.07 19.56 3.47
5 19.75 15.53 3.43 22.01 15.62 3.48 22.75 16.98 3.50 24.25 17.03 3.54 25.01 18.40 3.56 26.51 18.32 3.59 28.01 19.52 3.62
10 19.55 15.50 3.85 21.78 15.60 3.91 22.51 16.95 3.94 24.00 17.01 3.97 24.74 18.37 4.00 26.23 18.31 4.03 27.71 19.49 4.08
15 18.99 15.32 3.99 21.14 15.58 4.05 21.87 16.93 4.07 23.30 16.98 4.11 24.02 18.34 4.13 25.47 18.27 4.17 26.90 19.45 4.22
20 19.24 15.47 4.44 21.42 15.73 4.51 22.17 17.09 4.52 23.62 17.14 4.57 24.35 18.53 4.60 25.81 18.45 4.64 27.28 19.65 4.68
25 19.42 15.47 5.26 21.64 15.73 5.34 22.39 17.11 5.37 23.86 17.16 5.42 24.60 18.54 5.45 26.07 18.47 5.50 27.55 19.67 5.56
30 19.05 14.71 6.01 21.22 14.95 6.09 21.95 16.26 6.12 23.38 16.31 6.19 24.11 17.62 6.22 25.55 17.54 6.27 27.00 18.70 6.34
35 17.38 14.37 6.70 19.35 14.70 6.79 20.02 15.98 6.84 21.35 16.03 6.91 22.00 17.31 6.93 23.32 17.24 7.01 24.65 18.37 7.08
40 17.21 13.57 6.34 19.17 13.96 6.43 19.82 15.19 6.48 21.13 15.23 6.53 21.78 16.45 6.56 23.09 16.39 6.63 24.39 17.45 6.70
46 13.70 12.30 6.18 15.27 13.21 6.26 15.78 14.00 6.30 16.81 14.41 6.36 17.35 15.56 6.40 18.39 15.49 6.46 19.42 16.49 6.52
- 159 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
