6. External input and output
6-1. Indoor unit
Connector
Input Output Remarks
Other than high
static pressure
duct type
High static
pressure duct
type
CN102 CN114
Control
(Operation/Stop or
Forced stop)
—
For details, refer to
external input and
output settings.
CN103 CN115 — Operation status
CN6 CN14 — Fresh air control
CN10 (Duct only) CN15 — Auxiliary heater
¢ Correspondence list
Name of types Model
External input External output
Control
(Operation/Stop
or Forced stop)
Operation status
Fresh air
control
Auxiliary heater
Compact
cassette
18 ● ● ● —
22 ● ● ● —
24 ● ● ● —
Cassette
30 ● ● ● —
36 ● ● ● —
45 ● ● ● —
Slim duct 18 ● ● ● ●
Duct
22 ● ● ● ●
24 ● ● ● ●
30 ● ● ● ●
36 ● ● ● ●
45 ● ● ● ●
Floor/Ceiling
18 ● ● — —
22 ● ● — —
24 ● ● — —
Ceiling
30 ● ● ● —
36 ● ● ● —
45 ● ● ● —
- 225 -
6-1. Indoor unit 6. External input and output
