Fujitsu AO G24LBCB Series User Manual

1-4. Model: UTP-SX254A
Unit: mm
Port diameters
Liquid pipe Q’ty Gas pipe Q’ty
Ø9.52
Ø9.52
Ø9.52
Ø12.70
1
Ø15.88
Ø15.88
Ø15.88
Ø19.05
1
Dimensions
Liquid pipe Gas pipe
390
53
15
15
15
80
362
53
15
15
15
90
Heat insulation cover
Liquid pipe Q’ty Gas pipe Q’ty
1 1
Others
Adapter Q’ty
Ø6.35
Ø9.52
2
- 329 -
1-4. Model: UTP-SX254A 1. Branch pipes
OPTIONAL
PARTS
OPTIONAL PARTS
