Accessories
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Insulation 4 4
Duct flange 2 Cable tie 1
Cover 2
Extension wire for
louver
White
Red
1 set
Screw 16
Extension wire for
receiver kit
1
Hook plate 2 set
Wire
(External output 1)
1
Shutter plate 1
Wire
(External output 2)
1
Insulation 1 2
Wire
(External output 3)
1
Insulation 2 1 Bolt 4
Insulation 3 3
- 306 -
10-3. Fresh air intake kit for cassette type (UTZ-VXRA) 10. Optional parts installation
