Fujitsu AO G24LBCB Series User Manual

¢
Cooling capacity (Double twin)

Compact cassette type
Model: AUYG22LVLA × 4
AFR
m
3
/h
3,720
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 15.68 3.14 22.49 15.78 3.20 23.25 17.16 3.22 24.78 17.22 3.25 25.55 18.58 3.26 27.08 18.51 3.30 28.62 19.72 3.33
-10 19.98 15.53 3.15 22.27 15.62 3.21 23.02 16.99 3.22 24.55 17.04 3.25 25.30 18.40 3.27 26.82 18.33 3.30 28.34 19.52 3.33
0 19.80 15.38 3.36 22.05 15.48 3.40 22.80 16.82 3.43 24.30 16.88 3.46 25.05 18.22 3.48 26.57 18.14 3.52 28.07 19.33 3.55
5 19.75 15.34 3.50 22.01 15.43 3.56 22.75 16.78 3.58 24.25 16.83 3.62 25.01 18.18 3.64 26.51 18.10 3.67 28.01 19.28 3.71
10 19.55 15.31 3.94 21.78 15.41 4.00 22.51 16.75 4.03 24.00 16.81 4.06 24.74 18.15 4.09 26.23 18.09 4.12 27.71 19.25 4.17
15 18.99 15.14 4.08 21.14 15.39 4.14 21.87 16.72 4.16 23.30 16.77 4.20 24.02 18.12 4.22 25.47 18.05 4.26 26.90 19.22 4.31
20 19.24 15.28 4.54 21.42 15.54 4.61 22.17 16.89 4.62 23.62 16.94 4.67 24.35 18.30 4.70 25.81 18.23 4.75 27.28 19.41 4.79
25 19.42 15.29 5.38 21.64 15.55 5.46 22.39 16.90 5.49 23.86 16.95 5.54 24.60 18.32 5.57 26.07 18.25 5.63 27.55 19.43 5.68
30 19.05 14.53 6.14 21.22 14.77 6.23 21.95 16.06 6.26 23.38 16.11 6.33 24.11 17.40 6.36 25.55 17.33 6.41 27.00 18.47 6.49
35 17.38 14.20 6.85 19.35 14.52 6.95 20.02 15.79 6.99 21.35 15.84 7.06 22.00 17.11 7.09 23.32 17.03 7.16 24.65 18.15 7.23
40 17.21 13.41 6.48 19.17 13.80 6.57 19.82 15.00 6.62 21.13 15.05 6.68 21.78 16.25 6.71 23.09 16.19 6.78 24.39 17.24 6.85
46 13.70 12.15 6.32 15.27 13.05 6.40 15.78 13.83 6.44 16.81 14.24 6.50 17.35 15.37 6.54 18.39 15.31 6.61 19.42 16.29 6.67

Duct type
Model: ARYG22LMLA × 4
AFR
m
3
/h
4,400
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 16.11 3.08 22.49 16.21 3.13 23.25 17.62 3.15 24.78 17.68 3.18 25.55 19.08 3.19 27.08 19.01 3.23 28.62 20.26 3.26
-10 19.98 15.95 3.09 22.27 16.05 3.14 23.02 17.45 3.15 24.55 17.50 3.18 25.30 18.90 3.20 26.82 18.82 3.23 28.34 20.05 3.26
0 19.80 15.80 3.29 22.05 15.90 3.33 22.80 17.27 3.36 24.30 17.33 3.39 25.05 18.71 3.41 26.57 18.64 3.44 28.07 19.85 3.47
5 19.75 15.76 3.43 22.01 15.85 3.49 22.75 17.23 3.51 24.25 17.28 3.54 25.01 18.67 3.56 26.51 18.59 3.60 28.01 19.81 3.63
10 19.55 15.73 3.86 21.78 15.83 3.92 22.51 17.20 3.94 24.00 17.26 3.98 24.74 18.64 4.00 26.23 18.57 4.04 27.71 19.78 4.09
15 18.99 15.55 3.99 21.14 15.80 4.05 21.87 17.18 4.08 23.30 17.23 4.11 24.02 18.61 4.14 25.47 18.54 4.17 26.90 19.74 4.22
20 19.24 15.69 4.44 21.42 15.96 4.51 22.17 17.35 4.53 23.62 17.40 4.58 24.35 18.80 4.60 25.81 18.72 4.65 27.28 19.94 4.69
25 19.42 15.70 5.27 21.64 15.97 5.35 22.39 17.36 5.38 23.86 17.41 5.43 24.60 18.82 5.46 26.07 18.74 5.51 27.55 19.96 5.56
30 19.05 14.92 6.01 21.22 15.17 6.10 21.95 16.50 6.13 23.38 16.55 6.20 24.11 17.87 6.22 25.55 17.80 6.28 27.00 18.97 6.35
35 17.38 14.58 6.70 19.35 14.91 6.80 20.02 16.22 6.84 21.35 16.27 6.91 22.00 17.57 6.94 23.32 17.50 7.01 24.65 18.64 7.08
40 17.21 13.77 6.35 19.17 14.17 6.43 19.82 15.41 6.48 21.13 15.45 6.54 21.78 16.69 6.57 23.09 16.63 6.64 24.39 17.71 6.71
46 13.70 12.48 6.19 15.27 13.40 6.27 15.78 14.20 6.31 16.81 14.62 6.37 17.35 15.79 6.41 18.39 15.72 6.47 19.42 16.73 6.53

Floor/Ceiling type
Model: ABYG22LVTA × 4
AFR
m
3
/h
3,920
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 15.68 3.14 22.49 15.78 3.20 23.25 17.16 3.22 24.78 17.22 3.25 25.55 18.58 3.26 27.08 18.51 3.30 28.62 19.72 3.33
-10 19.98 15.53 3.15 22.27 15.62 3.21 23.02 16.99 3.22 24.55 17.04 3.25 25.30 18.40 3.27 26.82 18.33 3.30 28.34 19.52 3.33
0 19.80 15.38 3.36 22.05 15.48 3.40 22.80 16.82 3.43 24.30 16.88 3.46 25.05 18.22 3.48 26.57 18.14 3.52 28.07 19.33 3.55
5 19.75 15.34 3.50 22.01 15.43 3.56 22.75 16.78 3.58 24.25 16.83 3.62 25.01 18.18 3.64 26.51 18.10 3.67 28.01 19.28 3.71
10 19.55 15.31 3.94 21.78 15.41 4.00 22.51 16.75 4.03 24.00 16.81 4.06 24.74 18.15 4.09 26.23 18.09 4.12 27.71 19.25 4.17
15 18.99 15.14 4.08 21.14 15.39 4.14 21.87 16.72 4.16 23.30 16.77 4.20 24.02 18.12 4.22 25.47 18.05 4.26 26.90 19.22 4.31
20 19.24 15.28 4.54 21.42 15.54 4.61 22.17 16.89 4.62 23.62 16.94 4.67 24.35 18.30 4.70 25.81 18.23 4.75 27.28 19.41 4.79
25 19.42 15.29 5.38 21.64 15.55 5.46 22.39 16.90 5.49 23.86 16.95 5.54 24.60 18.32 5.57 26.07 18.25 5.63 27.55 19.43 5.68
30 19.05 14.53 6.14 21.22 14.77 6.23 21.95 16.06 6.26 23.38 16.11 6.33 24.11 17.40 6.36 25.55 17.33 6.41 27.00 18.47 6.49
35 17.38 14.20 6.85 19.35 14.52 6.95 20.02 15.79 6.99 21.35 15.84 7.06 22.00 17.11 7.09 23.32 17.03 7.16 24.65 18.15 7.23
40 17.21 13.41 6.48 19.17 13.80 6.57 19.82 15.00 6.62 21.13 15.05 6.68 21.78 16.25 6.71 23.09 16.19 6.78 24.39 17.24 6.85
46 13.70 12.15 6.32 15.27 13.05 6.40 15.78 13.83 6.44 16.81 14.24 6.50 17.35 15.37 6.54 18.39 15.31 6.61 19.42 16.29 6.67
- 163 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA

Fujitsu AO G24LBCB Series Specifications
