Double twin type
• Connection example 1
SetASetB SetC
01 03
(00)
Refrigerant pipe
Indoor unit
Outdoor unit
Connection cable
Remote controller cable
<Double twin>
SetASetB SetC
(00)(00)(00)
SetASetB SetC
01 01
(00)
SetASetB SetC
01 02
(00)
Wired remote controller
Junction box
it
• Connection example 2
SetASetB SetC
01 03
(00)
Refrigerant pipe
Indoor unit
Outdoor unit
Remote controller cable
<Double twin>
SetASetB SetC
(00)(00)(00)
SetASetB SetC
01 01
(00)
SetASetB SetC
01 02
(00)
Wired remote controller
Junction box
it
SetASetB SetC
01 07
01
Connection cable
Remote controller cable
<Double twin>
SetASetB SetC
(00)
01
04
SetASetB SetC
01 05
01
SetASetB SetC
01 06
01
NOTE: (00) is factory setting.
- 223 -
5-1. Indoor unit setting 5. System setting
SYSTEM
DESIGN
SYSTEM
DESIGN
