Fujitsu AOU12RLFC

 Multiple outdoor unit installation
• When the upper space is open:
Unit: in (mm)
When there are obstacles at the rear only. When there are obstacles at the front only.
12 (300) or more
60 (1,500)
or more
When there are obstacles at the front and
rear.
20 (500)
or more
60 (1,500)
or more
• When there is an obstruction in the upper space:
Unit: in (mm)
When there are obstacles at the rear and above.
60 (1,500)
or more
60 (1,500)
or more
20 (500) or more
Max. 11 (300)
- 111 -
3-3. Models: AOU42RGLX and AOU48RGLX 3. Installation space
OUTDOOR UNIT AOU12-48R OUTDOOR UNIT AOU12-48R
