Fujitsu AOU12RLFC

To Previous Page

15. Optional parts

Exterior Part name Model name Summary

External

connect kit

UTY-XWZXZ3

Use to operate the external input and

output functions of outdoor unit.

(For 42 and 48 models)

- 145 -

15. Optional parts

OUTDOOR UNIT

AOU12-48R

OUTDOOR UNIT

AOU12-48R
