Fujitsu AOU12RLFC Design & Technical Manual

2. Dimensions
2-1. Model: ARU12RGLX
Unit: in (mm)
Air
Gas pipe
Drain
port
Control
box
Liquid pipe
Side view (L) Side view (R)Top view
Front view
Rear view
29-1/8 (740)
25-9/16 (650)
P3-15/16 × 5 = 19-11/16
(P100 × 5 = 500)
1 (25)
1 (25)
1-7/8
(47)
24-13/16 (631)
2-3/8 (60)
27-9/16 (700)
1-15/16
(49)
1-15/16
(49)
27-9/16 (700)
7-1/4
(184)
18-3/16 (462)
P3-15/16 × 4
= 15-3/4
(P100 × 4 = 400)
1-1/4
(31)
1 (25)
12-5/8 (320)
11 (280)
5-1/16
(128)
2-11/16
(68)
11-13/16 (300)
1-1/8 (29)
8-1/4
(210)
5-11/16
(145)
11-13/16
(300)
2-15/16
(75)
5-7/8
(150)
7-1/2
(190)
Ø4-15/16
(Ø125)
5-1/2
(140)
Ø3/16
(Ø4)
Ø3/16
(Ø4.5)
6-5/16
(160)
3-1/8
(80)
5-1/2
(139)
3-15/16 (100)
2-5/16
(59)
Ø3/16
(Ø4.5)
8-9/16
(217)
2-1/4
(57)
2-5/8 (66)
3-3/8
(86)
1-5/8
(41)
8-11/16
(220)
7/8 (22)
10-1/16
(255)
- 8 -
2-1. Model: ARU12RGLX 2. Dimensions
DUCT TYPE ARU12-48RGLX DUCT TYPE ARU12-48RGLX
