Fujitsu AOYG36LBLA5 User Manual

NOTES:
• *1: By using this function, the wiring is automatically corrected according to the piping.
• *2: When correcting the wiring manually, please disconnect the power supply or turn off
the breaker during results display, and then change the wiring manually according to the
obtained test results.
For example, in Example 1, the wirings connected to the terminals B and C is to be ex-
changed manually.
<Result Table>
ABCDE F
1

2

3

4

5

6

7

ABCDE F
5. During results display, press the "CHECK" switch for 3 seconds or more.
After LEDs A to F have lit in turn, all LEDs will light up indicating that the automatic wiring
correction is completed.
(2-blink)
FEDC
MONITOR
ERROR
BA
POWER
MODE
6. Disconnect the power supply or turn off the breaker and wait 10 minutes then turn the power
back on and perform test run.
NOTE: If you do not disconnect the power supply or turn off the breaker, normal operation
is not possible.
Notices:
• If an error occurs during check run it will be suspended. Correct the error and start check run
again.
• After the check run, if automatic wiring correction is carried out, the indoor unit’s position will
be modified to match the piping. (Note that the display of the optional remote controller
changes.)
• If you start check run again after the automatic wiring correction is finished, the modification
will be reset.
- 407 -
OUTDOOR UNIT AOYG45LBLA6

Fujitsu AOYG36LBLA5 Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Compressor type	Rotary
Gas hose diameter	9.52 mm
Hose length (max)	80 m
Hose length (min)	25 m
Inverter technology	-
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	12500 W
Heating capacity in watts (max)	14000 W
Heating capacity in watts (min)	3500 W
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	370 mm
Outdoor unit width	970 mm
Outdoor unit height	998 mm
Outdoor unit weight	94000 g
Outdoor units quantity	1
Outdoor unit noise level	67 dB
Outdoor unit sound power level	68 dB
