1-9. ELECTRONIC EXPANSION VALVE CONTROL
The compressor won't enter operation status for 3 minutes after the compressor is stopped,
even if any operation is given.
1-10 PREVENT TO RESTART FOR 3 MINUTES ( 3 MINUTES ST )
01-11
The most proper opening of the electronic expansion valve is calculated and controlled under the
present operating condition based on the following values.
The compressor speed, the temperatures detected by the discharge temperature sensor, the
indoor heat exchanger sensor
, the outdoor heat exchanger sensor
, and the outdoor temperature sensor.
Pulse range
70 ~ 500 pulse
(1) Pulse range of EEV
(2) The EEV is set up at 500 pulses when the compressor is stopped.
(3) Initialization (Input of 528 pulses toward closing direction) is operated under
the following condition.
* When the power is turned on.
* 4 hours has passed since the last initialization, and 3 minutes has passed after
the compressor stop.
(If 12 hours has passed since the last initialization, the compressor is compulsorily stopped.)
All Models
COOLING / DRY
HEATING
Operation
60 ~ 500 pulse
When the power was interrupted by a power failure, etc. during operation, the operation contents
at that time are memorized and when power is recovered, operation is automatically resumed with
the memorized operation contents.
(Table 8 : Operation contents memorized when the power is interrupted)
Operation mode
Set temperature
Set air flow
Thermistor detected position
1-11. AUTO RESTART
Timer mode
Wired remote controller
(When Memory Backup : Disable)
Wired remote controller
(When Memory Backup : Enable)
OFF Timer
ON Timer
WEEKLY Timer
T
emperature
SET
BACK Timer
: Memorize
: Not memorize
*It is necessary to set on the DIP-SW1-No,6 of the wired remote controller,
to enable the memory backup.
Refer to the installation manual of wired remote controller for details.
