1-2. HEATING OPERATION
1-2-1 HEATING CAPACITY CONTROL
01-02
A sensor (room temperature thermistor) built in the indoor unit will usually perceive
difference or variation between a set temperature and present room temperature, and
controls the operation frequency of the compressor.
* If the room temperature is lower 3°C than a set temperature,
the compressor operation frequency will attain to maximum performance.
* If the room temperature is higher 2.5°C than a set temperature, the compressor
will be stopped.
* When the room temperature is between +2.5°C to -3°C of the setting temperature,
the compressor frequency is controlled within the range shown in Table2.
However, the maximum frequency is limited in the range shown in Fig. 2 based on
the outdoor temperature.
( Table 2 : Compressor Frequency Range )
( Fig.2 : Limit of Maximum Frequency based on Outdoor Temperature )
Outdoor air
temperature
C zone
B zone
A zone
17°C
12°C
19°C
14°C
minimum
frequency
maximum
frequency
30rps 85rps
AO* A72LALT
30rps 100rps
AO* A90LALT
Hi Me Lo
90rps 79rps 70rps
A zone
B zone
C zone
AO* A72LALT
100rps 90rps 79rps
A zone
B zone
C zone
AO* A90LALT
Fan speed mode
