01-27
1-26-6 Field Setting and Monitor Mode List
Operation of
each part
10
Rotational speed of outdoor unit fan motor
The rotational speed of the outdoor unit fan motor is displayed
[ 0 ~ 999 ] rpm
11
Rotational speed of INV compressor
The rotational speed of the compressor is displayed
[ 0 ~ 999 ] rps
12
Current value of INV compressor
Current value of INV compressor is displayed
[ 0.00 ~ 99.99 ] A
14
Pulse of EEV1
Pulse of EEV1 is displayed
[ 0 ~ 9999 ] pls
Time guard
21
INV compressor accumulated time
[ Cooling ]
Accumulated time is displayed in the cooling operation of the
INV compressor
[ 0 ~ 9999 ]
10hour
22 INV compressor accumulated time
[ Heating ]
Accumulated time is displayed in the heating operation of the
INV compressor
[ 0 ~ 9999 ]
10hour
Refrigerant
cycle data 1
30
Information on Thermistor 1
(Discharge Pipe Temperature Thermistor)
The value of the Thermistor 1 is displayed
[ -99.9 ~ 999.9 ]
°C or °F
32 Information on Thermistor 3
(Outdoor Temperature Thermistor)
The value of the Thermistor 3 is displayed
[ -99.9 ~ 999.9 ]
°C or °F
34 Information on Thermistor 5
(Heat Exchanger Temperature Thermistor)
The value of the Thermistor 5 is displayed
[ -99.9 ~ 999.9 ]
°C or °F
39 Information on Thermistor 10
(Compressor Temperature Thermistor)
The value of the Thermistor 10 is displayed
[ -99.9 ~ 999.9 ]
°C or °F
50 Information on pressure sensor 1 The value of the pressure sensor 1 is displayed
Refrigerant
cycle data 3
If unit is [MPa], it is displayed as [ 0.00 ~ 9.99 ]
[psi], it is displayed as [ 0.0 ~ 999.9 ]
51
Information on pressure sensor 2
The value of the pressure sensor 2 is displayed
If unit is [MPa], it is displayed as [ 0.00 ~ 9.99 ]
[psi], it is displayed as [ 0.0 ~ 999.9 ]
[ F1 ]
Monitor mode
Setting Mode
ITEM
CODE No.
Information contents
Classification
Setting Mode
ITEM
CODE No.
Setting Function
Default
Install
00
Pipe length setting
00 40-65m
Setting mode
02
65-90m
Correction
13
Defrost setting shift 1
(Defrosting time)
00
End temperature:Normal
01
End temperature:Higher
Change of 30
Energy saving level setting
00
Level 1 (stop)
01
Level 2 (operated at 50% capacity)
02
Level 3 (operated at 75% capacity)
03
Level 4 (operated at 100% capacity)
Low noise
41 Low noise mode setting
00
Off (Normal operation)
01
On (Low noise mode operation is always done)
42
Low noise mode operation
00
Level 1 (dB)
01
Level 2 (dB)
[ F2 ]
ITEM
CODE No.
setting
level setting
function 2
Classification
Defrost setting shift 2
(Defrosting start time)
02
00
01
02
End temperature:Lower
Start temperature:Normal
Start temperature:Higher
Start temperature:Lower
Start time:Normal
Start time:Longer
Start time:Shorter
End time:Normal
End time:Longer
End time:Shorter
Level 3 (dB)
02
Forced
operation
00 Cooling test run
Forced thermostat-ON in Cooling
Function mode
01 Heating test run Forced thermostat-ON in Heating
02 Test run stop Test run is stopped
Clear
30 Error history clear All the abnormal code histories are cleared
33 INV compressor accumulated time clear Accumulated time of the INV compressor becomes [ 0 ]
35 Field setting all clear Return to default the all set items
Setting Mode
ITEM
CODE No.
Setting Function
[ F3 ]
1 time ago
(Newest)
Error History
Display Mode
2 times ago
Meaning of Error History Number
ITEM
CODE No.
Information contents
[ F9 ]
00
01
02
03
Error history
4 times ago
3 times ago
Refer to TROUBLE SHOOTING
