- 66 -
OUTDOOR UNIT AOGA30-60F
5-2. Models: AOGA36FRTAS, AOGA45FRTAS, and AOGA60-
FRTAS
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 20 30 40 50
Height difference H (m)
Indoor unit is higher
than outdoor unit *1
30 - - - - 0.893 0.867 0.840
25 - - - - 0.893 0.867 0.840
20 - - - 0.919 0.893 0.867 0.840
15 - - - 0.919 0.893 0.867 0.840
10 - - 0.985 0.919 0.893 0.867 0.840
7.5 - 1.000 0.985 0.919 0.893 0.867 0.840
5 1.014 1.000 0.985 0.919 0.893 0.867 0.840
0 1.014 1.000 0.985 0.919 0.893 0.867 0.840
Indoor unit is lower
than outdoor unit *2
-5 1.005 0.992 0.977 0.912 0.886 0.860 0.834
-7.5 - 0.988 0.973 0.908 0.882 0.856 0.830
-10 - - 0.969 0.905 0.879 0.853 0.827
-15 - - - 0.897 0.872 0.846 0.820
-20 - - - 0.890 0.864 0.839 0.814
-25 - - - - 0.857 0.832 0.807
-30 - - - - 0.850 0.825 0.800
