Fujitsu ARXG54KHTA - Sound Level Check Point

6-2. Sound level check point
enohporciM
Measuring ductMeasuring duct
Set the static pressure
as rating in this area
AIR
2 m
1.5 m
1 m
enohporciM
Front viewSide view
- 16 -
6-2. Sound level check point 6. Operation noise (sound pressure)
DUCT TYPE ARXG45, 54KHTA DUCT TYPE ARXG45, 54KHTA
