11. Optional parts
11-1. Controllers
Exterior Part name Model name Summary
Wired remote
controller
UTY-RVNYM
Large and full-dot liquid crystal screen,
wide and large keys easy to press,
user-intuitive arrow key.
Wire type: Polar 3-wire
Wired remote
controller
UTY-RNNYM
Room temperature can be controlled
by detecting the temperature
accurately with built-in thermo sensor.
Wire type: Polar 3-wire
Simple remote
controller
UTY-RSNYM
Compact remote controller
concentrates on the basic functions
such as Start/Stop, fan control,
temperature setting, and operation
mode.
Wire type: Polar 3-wire
NOTES:
• Available functions may differ by the remote controller. For details, refer to the operation manu-
al.
• When using a Wireless LAN adapter, group controlling system of the wired remote controller is
prohibited.
- 30 -
11-1. Controllers 11. Optional parts
DUCT TYPE
ARXG45, 54KHTA
DUCT TYPE
ARXG45, 54KHTA
