Fujitsu ARXG54KHTA - Sound Level Check Point

9-2. Sound level check point
1 m
1.5 m
Airflow
MicrophoneMicrophone
Front
Front viewSide view
NOTE: Detailed shape of the actual outdoor unit might be slightly different from the one illustrated
above.
- 45 -
9-2. Sound level check point 9. Operation noise (sound pressure)
OUTDOOR UNIT AOYG45, 54KRTA OUTDOOR UNIT AOYG45, 54KRTA
