CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL
: AS
A09LK
MODEL
: AS
A12LK
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR 11.8
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
20 2.34 1.60 0.55 2.61 1.61 0.56 2.70 1.75 0.56 2.87 1.76 0.56 2.96 1.90 0.57 3.14 1.89 0.57 3.32 2.01 0.58
25 2.22 1.52 0.62 2.48 1.53 0.62 2.56 1.66 0.63 2.73 1.67 0.63 2.81 1.80 0.64 2.98 1.79 0.64 3.15 1.91 0.65
30 2.10 1.44 0.68 2.34 1.44 0.69 2.42 1.57 0.70 2.58 1.58 0.70 2.66 1.70 0.71 2.82 1.70 0.72 2.98 1.81 0.72
35 1.98 1.35 0.75 2.20 1.36 0.76 2.28 1.48 0.77 2.43 1.48 0.78 2.50 1.60 0.78 2.65 1.59 0.79 2.80 1.70 0.80
40 1.76 1.20 0.75 1.96 1.21 0.76 2.03 1.32 0.77 2.16 1.32 0.78 2.23 1.43 0.78 2.36 1.42 0.79 2.50 1.51 0.80
43 1.63 1.12 0.75 1.82 1.12 0.76 1.88 1.22 0.77 2.00 1.22 0.77 2.07 1.32 0.78 2.19 1.32 0.78 2.31 1.40 0.79
AFR 11.8
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
20 3.18 2.20 0.73 3.55 2.21 0.74 3.67 2.41 0.74 3.91 2.41 0.75 4.03 2.61 0.75 4.27 2.60 0.76 4.51 2.77 0.77
25 3.03 2.09 0.82 3.37 2.11 0.84 3.49 2.29 0.84 3.72 2.30 0.85 3.83 2.48 0.85 4.06 2.47 0.86 4.29 2.63 0.87
30 2.86 1.98 0.92 3.19 1.99 0.94 3.30 2.17 0.94 3.52 2.17 0.95 3.63 2.35 0.96 3.84 2.34 0.96 4.06 2.49 0.97
35 2.69 1.86 1.02 2.99 1.87 1.04 3.09 2.03 1.04 3.30 2.04 1.05 3.40 2.20 1.06 3.60 2.19 1.07 3.81 2.33 1.08
40 2.27 1.57 0.95 2.53 1.58 0.97 2.62 1.72 0.97 2.79 1.72 0.98 2.87 1.86 0.99 3.05 1.85 1.00 3.22 1.97 1.01
43 2.09 1.45 0.95 2.33 1.45 0.97 2.41 1.58 0.97 2.57 1.59 0.98 2.65 1.71 0.99 2.81 1.71 1.00 2.96 1.82 1.01
