- (02 - 02) -
OUTDOOR UNIT
AO
R09-12LK
OUTDOOR UNIT
AO
R09-12LK
INSTALLATION PLACE
If the space is larger that is stated, the condition will be the same as that are no obstacles.
600 mm or more
100 mm or more
200 mm or more
100 mm or more
250 mm or more
(Service space)
DIMENSIONS2.
MODEL
: AO
R09LK, AO
R12LK
(Unit : mm)
19.5
660
20
540
68
290
330
38
320
353
φ20
103
454
