Fujitsu AS*A09LKC Design & Technical Manual

- (01 - 05) -
WALL MOUNTED TYPE AS

A09-12LK
WALL MOUNTED TYPE AS

A09-12LK
SPECIFICATIONS3.
Note :
Specications are based on the following conditions.
Cooling:Indoor temperature of 27°C CDB/ 19°C CWB.and outdoor temperature of 35°C CDB/ 24°C CWB.
Heating:Indoor temperature of 20°C CDB/ 15°C CWB.and outdoor temperature of 7°C CDB/ 6°C CWB.
Pipe length : 5m,Height difference : 0m(Outdoor unit-Indoor unit)
The maximum current is the maximum value when the operated within the operation range(temperature).
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name AS
¾
A09LKC AS
¾
A12LKC
Power source 230V~ 50Hz
Available voltage range 198-264V~ 50Hz
European energy label
Cooling A A
Heating A A
Capacity
Cooling
Rated
kW 2.50 3.40
BTU/h 8,500 11,600
Min-Max
kW 0.5~3.0 0.9~3.8
BTU/h 1,700~10,200 3,100~13,000
Heating
Rated
kW 3.20 4.00
BTU/h 10,900 13,600
Min-Max
kW 0.5~3.9 0.9~5.6
BTU/h 1,700~13,300 3,100~19,100
Input power
Cooling
Rated
kW
0.78 1.06
Min-Max 0.25~1.02 0.25~1.40
Heating
Rated 0.885 1.105
Min-Max 0.25~1.15 0.25~1.99
Current
Cooling
Rated
A
4.2 4.9
Max 5.5 6.5
Heating
Rated 4.8 5.2
Max 5.5 9.0
EER Cooling
kW/kW
3.21 3.21
COP Heating 3.62 3.62
SENSIBLE CAPACITY Cooling kW 1.6 2.2
POWER FACTOR
Cooling
%
81 94
Heating 80 92
Moisture removal l/h (pints/h) 1.3 1.8
Fan
Air ow rate
Cooling
High
m
3
/h
710
Med 590
Low 430
Quiet 260
Heating
High 730
Med 590
Low 460
Quiet 290
Type × Q'ty Cross ow fan×1
Motor output W 30
Sound pressure level
Cooling
High
dB(A)
43
Med 38
Low 33
Quiet 21
Heating
High 43
Med 38
Low 33
Quiet 21
Heat exchanger type
Dimensions
(H × W × D)
mm
256 × 630 × 20
Fin pitch 1.1
Rows Stages 2 × 16
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour
WHITE
Approximate colour of MUNSELL N 9.25/
Dimensions
(H × W × D)
Net
mm
260 × 790 × 202
Gross 259 × 840 × 328
Weight
Net
kg(lb)
7.5 (17)
Gross 9.5 (21)
Connection pipe
Size
Liquid
mm
Φ6.35 (Φ1/4 in)
Gas Φ9.52 (Φ3/8 in)
Method Flare
Operation range
Cooling
°C 18~32
%RH 80 or less
Heating °C 30 or less
Remote controller type Wireless
Drain pipe
Material PP+LLDPE
Size mm Outer diameter:21 / Outer diameter:13.6

Fujitsu AS*A09LKC Specifications

General

Brand	Fujitsu
Model	AS*A09LKC
Category	Air Conditioner
Language	English
