Fujitsu AS*A09LKC Design & Technical Manual

- (02 - 01) -
OUTDOOR UNIT AO

R09-12LK
OUTDOOR UNIT AO

R09-12LK
SPECIFICATIONS1.
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB / 24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length : 5 m, Height difference : 0 m.(Outdoor unit - Indoor unit)
The maximum current is the maximum value when the operated within the operation range(temperature).
Type INVERTER COOLING & HEATING
Model name AO
Û
R09LKC AO
Û
R12LKC
Power source 230V~ 50Hz
Available voltage range 198-264V~ 50Hz
Starting current A 4.8 5.2
Fan
Air ow rate
Cooling
m
3
/h
1,720 1,830
Heating 1,510 1,600
Type × Q'ty Propeller fan×1
Motor output W 40
Sound pressure level
Cooling
dB(A)
45 50
Heating 45 50
Heat exchanger type
Dimensions (H × W × D)
mm
650 × 504 × 18.2 642 × 504 × 36.4
Fin pitch 1.3 1.4
Rows x Stages 1 × 24 2 × 24
Pipe type Copper
Fin type Aluminium
Compressor
Type × Q'ty Rotary×1
Motor output W 500 750
Refrigerant
Type R410A
Charge g 650 800
Refrigerant oil Type POE( VG74)
Enclosure
Material Steel
Colour
BEIGE
Approximate colour of MUNSELL 10YR 7.5/1.0
Dimensions
( H × W × D)
Net
mm
540 × 660 × 290 540 × 660 × 290
Gross 611 × 797 × 401 611 × 797 × 401
Weight
Net
kg(lb.)
22(48) 29(64)
Gross 25(55) 32(71)
Connection pipe
Size
Liquid
mm
Φ6.35 (Φ 1/4 in.)
Gas Φ9.52 (Φ 3/8 in.)
Method Flare
Max. length
m
20 (chargeless:15)
Max. height difference 15
Operation range
Cooling
°C
18 to 43
Heating -15 to 24
