Fujitsu AS*A09LKC Design & Technical Manual

- (01 - 09) -
WALL MOUNTED TYPE AS

A09-12LK
WALL MOUNTED TYPE AS

A09-12LK
HEATING CAPACITY6-2.
MODEL

: AS

A09LK
MODEL

: AS

A12LK
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC: Sensible Heat capacity (kW)
PI : Power Input (kW)
AFR 12.2
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC PI TC PI TC PI TC PI TC PI
-15 -16 2.05 0.95 2.00 0.97 1.96 0.99 1.91 1.01 1.86 1.03
-10 -11 2.33 0.97 2.28 0.99 2.22 1.01 2.16 1.03 2.11 1.05
-5 -7 2.67 1.00 2.61 1.02 2.54 1.04 2.48 1.07 2.42 1.09
0 -2 3.17 1.04 3.10 1.06 3.02 1.08 2.95 1.10 2.87 1.13
5 3 3.70 1.08 3.61 1.11 3.52 1.13 3.43 1.15 3.29 1.15
7 6 4.01 1.10 3.92 1.13 3.82 1.15 3.65 1.15 3.47 1.15
10 8 4.23 1.12 4.13 1.14 3.96 1.15 3.79 1.15 3.63 1.15
15 10 4.38 1.15 4.17 1.15 4.00 1.15 3.80 1.15 3.65 1.15
AFR 12.2
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC PI TC PI TC PI TC PI TC PI
-15 -16 3.40 1.96 3.29 1.99 3.15 1.99 3.01 1.99 2.87 1.99
-10 -11 3.76 1.96 3.65 1.99 3.49 1.99 3.34 1.99 3.19 1.99
-5 -7 4.18 1.96 4.05 1.99 3.88 1.99 3.71 1.99 3.55 1.99
0 -2 4.68 1.96 4.52 1.99 4.33 1.99 4.14 1.99 3.96 1.99
5 3 5.05 1.73 4.93 1.76 4.81 1.80 4.69 1.84 4.57 1.87
7 6 5.36 1.72 5.23 1.75 5.10 1.79 4.97 1.83 4.85 1.86
10 8 5.55 1.72 5.42 1.75 5.29 1.79 5.16 1.83 5.02 1.86
15 10 5.51 1.61 5.29 1.61 5.03 1.61 4.82 1.61 4.61 1.61
