Fujitsu AS*A09LKC Design & Technical Manual

- (01 - 20) -
WALL MOUNTED TYPE AS

A09-12LK
WALL MOUNTED TYPE AS

A09-12LK
Operating output setting11-2-2.
You can display air conditioner ON / OFF operation by e xternal o utput. •
Signal specication
z
No voltage contact. •
Contact capacity : Max. DC24V 10mA to 1A or less •
SHORT
OPEN
OPERATION
STOP
Indoor unit status
External output signal
Installation example
z
For operation display •
Blue
External
input
Vc
Ic
External
output
1
2
Purple
Indoor unit
External device
( Field supply )
Print circuit
board

Fujitsu AS*A09LKC Specifications

General

Brand	Fujitsu
Model	AS*A09LKC
Category	Air Conditioner
Language	English
