WALL MOUNTED TYPE
ASTG09-12KMCA
WALL MOUNTED TYPE
ASTG09-12KMCA
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL
: ASTG09KMCA
MODEL
:ASTG12KMCA
AFR: Airflow Rate (m
3
/min)
TC: Total Capacity (kW)
SHC: Sensible Heat Capacity (kW)
IP: Input Power (kW)
AFR 11.7
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 2.34 1.53 0.34 2.60 1.54 0.34 2.69 1.67 0.34 2.87 1.67 0.35 2.96 1.81 0.35 3.14 1.80 0.35 3.32 1.92 0.36
25 2.22 1.47 0.39 2.47 1.48 0.39 2.56 1.61 0.39 2.73 1.62 0.40 2.81 1.75 0.40 2.98 1.74 0.40 3.15 1.85 0.41
30 2.10 1.42 0.44 2.34 1.43 0.45 2.42 1.56 0.45 2.58 1.56 0.45 2.66 1.69 0.46 2.82 1.68 0.46 2.98 1.79 0.46
35 1.98 1.37 0.49 2.20 1.38 0.50 2.28 1.50 0.50 2.43 1.50 0.51 2.50 1.62 0.51 2.65 1.61 0.52 2.80 1.72 0.52
40 1.83 1.32 0.54 2.03 1.33 0.55 2.10 1.45 0.56 2.24 1.45 0.56 2.31 1.57 0.56 2.45 1.56 0.57 2.59 1.66 0.57
46 1.68 1.30 0.62 1.87 1.31 0.63 1.93 1.42 0.64 2.06 1.43 0.64 2.13 1.54 0.65 2.25 1.54 0.65 2.38 1.64 0.66
AFR 12.0
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
20 3.28 2.15 0.59 3.65 2.16 0.60 3.78 2.35 0.61 4.03 2.36 0.61 4.15 2.55 0.62 4.40 2.54 0.62 4.65 2.70 0.63
25 3.12 2.08 0.67 3.48 2.10 0.68 3.59 2.28 0.68 3.83 2.29 0.69 3.95 2.47 0.70 4.19 2.46 0.70 4.42 2.62 0.71
30 2.95 2.00 0.75 3.28 2.01 0.76 3.39 2.19 0.77 3.62 2.20 0.78 3.73 2.37 0.78 3.95 2.36 0.79 4.18 2.52 0.79
35 2.77 1.92 0.83 3.08 1.94 0.84 3.19 2.10 0.85 3.40 2.11 0.86 3.50 2.28 0.86 3.71 2.27 0.87 3.92 2.42 0.88
40 2.56 1.85 0.92 2.85 1.86 0.93 2.95 2.03 0.94 3.14 2.03 0.95 3.24 2.20 0.95 3.43 2.19 0.96 3.62 2.33 0.97
46 2.26 1.76 0.97 2.51 1.77 0.99 2.60 1.92 0.99 2.77 1.93 1.00 2.86 2.09 1.01 3.03 2.08 1.02 3.20 2.21 1.03
