Fujitsu ASTG09KMCA Design & Technical Manual

-
(
02 - 02
)
-
OUTDOOR UNIT AOTG09-12KMCA OUTDOOR UNIT AOTG09-12KMCA
DIMENSIONS2.
MODELS: AOTG09KMCA, AOTG12KMCA

(Unit: mm)
INSTALLATION PLACE

(Unit: mm)
If the space is larger than stated, the condition will be the same as those without any obstacles.

•
Height above the floor level should be 50 mm or more.

•
600 or more
100 or more
200 or more
100 or more
250 or more
(Service space)
790
290
352
7220
10 18
Top view
540
320
209
Side view
Side view
Front view
Airflow
175
110
9
20
540
4-ø11.3 mm
hole
Bottom view
45.4
Drain port (Ø20)
395
