Fujitsu ASTG09KMCA Design & Technical Manual

-
(
02 - 01
)
-
OUTDOOR UNIT AOTG09-12KMCA OUTDOOR UNIT AOTG09-12KMCA
SPECIFICATIONS1.
Type INVERTER HEAT PUMP
Model name AOTG09KMCA AOTG12KMCA
Power source 240 V ~ 50 Hz
Available voltage range 198 V - 264 V
Starting current A 3.3 4.2
Fan
Airflow
rate
Cooling
I/s
(m
3
/h)
472 (1700) 539 (1940)
Heating 428 (1540) 428 (1540)
Type × Q'ty Propeller fan × 1
Motor output W 50 50
Sound pressure level
Cooling
dB (A)
47 49
Heating 47 49
Sound power level 64 67
Heat exchanger type
Dimensions
(H × W × D)
mm
504 × 896 × 36.4
Fin pitch 1.3
Rows × Stages 2 × 24
Pipe type Copper
Fin
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue fin)
Compressor
Type × Q'ty Rotary × 1
Motor output W 750
Refrigerant
Type R32
Charge g 850
Refrigerant oil Type POE
Enclosure
Material Steel
Colour
Beige
Approximate colour of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
540 × 790 × 290
Gross 633 × 945 × 395
Weight
Net
kg
34
Gross 37
Connection pipe
Size
Liquid
mm
Ø 6.35
Gas Ø 9.52
Method Flare
Pre-charge length
m
20
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
10 to 46
Heating -15 to 24
International protection rating IPX4
NOTES :
Specifications are based on the following conditions.

•
Cooling: Indoor temperature of 27 °CDB / 19 °CWB and outdoor temperature of 35 °CDB / 24 °CWB.
Heating: Indoor temperature of 20 °CDB / 15 °CWB and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length: 7.5 m, Height difference: 0 m. (Outdoor unit - Indoor unit)
The protective function may work when using it in environment out of the temperature range mentioned above.

•
