Fujitsu ASTG09KMCA Design & Technical Manual

-
(
01 - 05
)
-
WALL MOUNTED TYPE ASTG09-12KMCA WALL MOUNTED TYPE ASTG09-12KMCA
SPECIFICATIONS3.
Type
WALL MOUNTED
INVERTER HEAT PUMP
Model name ASTG09KMCA ASTG12KMCA
Power source 240 V ~ 50 Hz
Available voltage range 198 V - 264 V
Star rating index 10-star standard
Cooling 5.0 3.5
Heating 5.0 4.5
Capacity
Cooling
Rated
kW 2.50 3.50
Btu/h 8,500 11,900
Min.-Max.
kW 0.90 - 3.60 0.90 - 4.10
Btu/h 3,100 - 12,200 3,100 - 13,900
Heating
Rated
kW 3.20 3.70
Btu/h 10,900 12,600
Min.-Max.
kW 0.90 - 5.30 0.90 - 5.60
Btu/h 3,100 - 18,000 3,100 - 19,100
Input power
Cooling
Rated
kW
0.51 0.86
Min.-Max. 0.25 - 1.14 0.25 - 1.38
Heating
Rated 0.65 0.81
Min.-Max. 0.25 - 1.60 0.25 - 1.70
Current
Cooling
Rated A
2.7 4.2
Heating 3.3 4.0
EER Cooling
kW/kW
4.90 4.07
COP Heating 4.92 4.57
Sensible capacity Cooling kW 1.62 2.28
Power factor
Cooling
%
79 85
Heating 82 84
Moisture removal l/h (pints/h) 1.3 (2.3) 1.8 (3.2)
Maximum operating
current *
Cooling
A
6.0 6.5
Heating 7.5 9.0
Fan
Airflow
rate
Cooling
High
I/s (m
3
/h)
194 (700) 200 (720)
Med 156 (560) 169 (610)
Low 125 (450) 133 (480)
Quiet 86 (310) 86 (310)
Heating
High 194 (700) 200 (720)
Med
156 (560) 169 (610)
Low 131 (470) 144 (520)
Quiet 92 (330) 92 (330)
Type × Q' ty Crossflow fan × 1
Motor output W 44
Sound pressure level
Cooling
High
dB (A)
40 42
Med 36 37
Low 31 32
Quiet 21 21
Heating
High 40 42
Med 34 37
Low 31 33
Quiet 22 22
Heat exchanger type
Dimensions
(H × W × D)
mm
Main: 320 × 630 × 20
Sub: 84 × 630 × 13.3
Fin pitch Main: 1.1, Sub: 1.4
Rows × Stages Main: 2 × 20, Sub: 1 × 4
Pipe type Copper
Fin type Aluminium
Enclosure
Material Polystyrene
Colour
White
Approximate colour of MUNSELL N9.25/
Dimensions
(H × W × D)
Net
mm
268 × 840 × 203
Gross 270 × 884 × 336
Weight
Net
kg
8.5
Gross 10.5
Connection
pipe
Size
Liquid
mm
Ø 6.35 (Ø 1/4 in.)
Gas Ø 9.52 (Ø 3/8 in.)
Method Flareless
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless
Drain hose
Material PP + LLDPE
Size mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
International Protection rating IPX0
NOTES :
Specifications are based on the following conditions.

•
Cooling: Indoor temperature of 27 °CDB / 19 °CWB and outdoor temperature of 35 °CDB / 24 °CWB.
Heating: Indoor temperature of 20 °CDB / 15 °CWB and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length: 7.5 m, Height difference: 0 m. (Outdoor unit - Indoor unit)
The protective function may work when using it in environment out of the temperature range mentioned above.

•
*: The maximum current is the maximum value when operated within the operation range.
