Fujitsu ASTG09KMCA Design & Technical Manual

-
(
01 - 10
)
-
WALL MOUNTED TYPE ASTG09-12KMCA WALL MOUNTED TYPE ASTG09-12KMCA
HEATING CAPACITY6-2.
MODEL

: ASTG09KMCA
MODEL

: ASTG12KMCA
AFR: Airflow Rate (m
3
/min)
TC: Total Capacity (kW)
IP: Input Power (kW)
AFR 11.7
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 2.76 1.08 2.69 1.10 2.63 1.12 2.56 1.15 2.50 1.17
-10 -11 3.23 1.16 3.15 1.19 3.07 1.21 3.00 1.23 2.92 1.26
-5 -7 3.69 1.24 3.61 1.27 3.52 1.30 3.43 1.32 3.34 1.35
0 -2 4.16 1.33 4.06 1.36 3.96 1.38 3.86 1.41 3.76 1.44
5 3 4.90 1.44 4.79 1.47 4.67 1.50 4.55 1.53 4.44 1.56
7 6 5.57 1.54 5.43 1.57 5.30 1.60 5.17 1.63 5.04 1.66
10 8 5.80 1.46 5.66 1.49 5.52 1.52 5.38 1.55 5.24 1.58
15 10 5.87 1.31 5.73 1.34 5.59 1.36 5.45 1.39 5.31 1.42
AFR 12.0
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-15 -16 3.03 1.14 2.96 1.17 2.89 1.19 2.82 1.21 2.74 1.24
-10 -11 3.50 1.24 3.42 1.27 3.33 1.29 3.25 1.32 3.17 1.34
-5 -7 3.92 1.32 3.82 1.34 3.73 1.37 3.64 1.40 3.54 1.43
0 -2 4.42 1.42 4.31 1.45 4.21 1.48 4.10 1.51 4.00 1.54
5 3 5.21 1.54 5.09 1.57 4.96 1.60 4.84 1.64 4.72 1.67
7 6 5.88 1.63 5.74 1.67 5.60 1.70 5.46 1.73 5.32 1.77
10 8 6.12 1.54 5.97 1.57 5.83 1.60 5.68 1.63 5.53 1.67
15 10 6.20 1.45 6.05 1.48 5.90 1.51 5.76 1.54 5.61 1.57
